*标准：
•ISO/IEC 11801
•ANSI/TIA-568-C.2
•RoHS/CE compliant
产品特性:
•性能种类=六类
•双绞线对数= 4
•导体直径(AWG) = 23
•导体：裸铜
•长度= 305米
•护套颜色=蓝色
· 屏蔽类型= 总铝箔屏蔽
· 工作温度(°C [°F]) = -20 – +75 [-4 – +167]
包装：木轴
◎ 应用范围:
10Base-T4, 100Base-TX, 100Base-VG-ANYLAN, 155MbpsATM, 622 Mbps ATM, 1000Base-T, 10GBase-T
*性能参数:
|
CATEGORY 6 FTP 4-PAIR CABLE: |
||||||||
|
FREQUENCY |
RL |
SRL |
ATTEN |
NEXT |
PSNEXT |
ELFEXT |
PSELFEXT |
DELAY |
|
(MHZ) |
(DB) |
(DB) |
(DB/100M) |
(DB/100M) |
(MHZ) |
(DB/100M) |
(DB/100M) |
(NS/100M) |
|
0.772 |
20 |
28 |
2 |
67.8 |
65.5 |
68.2 |
65 |
550 |
|
1 |
20 |
28 |
2 |
65.1 |
62.5 |
64.3 |
62 |
553 |
|
4 |
23 |
28 |
4 |
57.2 |
52.7 |
53.1 |
52 |
552 |
|
10 |
25 |
28 |
6.3 |
50.9 |
47.3 |
44.2 |
43 |
545 |
|
16 |
25 |
28 |
8 |
48.2 |
44.9 |
29.8 |
40 |
538 |
|
25 |
23.6 |
25 |
10.7 |
44.1 |
42.1 |
36.4 |
35 |
534 |
|
62.5 |
20.1 |
27 |
16.4 |
39.3 |
37.9 |
29.5 |
29 |
532 |
|
100 |
18.8 |
26.5 |
21.4 |
36.5 |
32.8 |
26.2 |
27.6 |
520 |
|
200 |
17.2 |
24.9 |
19.2 |
34.9 |
30.5 |
23.4 |
25.3 |
517 |
|
250 |
16.3 |
22.4 |
18.7 |
32.8 |
28.6 |
22.6 |
23.7 |
515 |
